Advantages:
Record 3K ultra HD video with audio and 32MP photo, video resolution 3K(2880x1616 25fps) and 1080P(1920x1080 30fps) optional, MP4 format, video coding H.265.
Manage camera on mobile APP, as well as preview camera, capture image, set up parameters, play back and download image.
Broadcast the camera's working status and remind the parameters setting when you operate the camera.
Adopts advanced low-power consumption PIR sensor and fast sensing&recording technology, 35 meters of sensing distance, it only takes 0.4S from triggering camera to finishing taking photo, standby current is only 50uA, which greatly prolongs the standby time of the camera.
All-round waterproof and dust-proof design, working temperature range from -40℃ to +70℃, can resist most of the harsh outdoor environment.
Features:
Model |
Parameters |
Image sensor |
Adopts 5Mega Pixels CMOS sensor |
Picture size |
5MP(2880X1616); 12MP(4608x2585); 32MP(7776 x 4363); |
Video resolution |
H.265 / MP4 format;3K(2880x1616 25fps), 1080P(1920x1080 30 fps),optional, record UHD video with audio recording. |
Lens |
FOV=100°; F=1.6 Auto IR-Cut; |
Photo burst |
1~3 |
The camera voice broadcast function |
automatically broadcasts the camera's working status and setting reminders when operating the camera |
Working mode |
Photo, Video, Photo + Video |
IR flash |
6 ultra-high brightness LED lights (940nm, 850nm, white light; optional) |
WiFi direct connection to set up camera |
After the phone is connected to the camera WiFi hotspot, you can set up parameters, preview image, download and replay photo and video etc. on APP. |
Wireless send |
After the camera takes photo or video, it can automatically connect to the wireless WIFI router to upload the original photo and video to the email or FTP server. |
WIFI distance |
60 meters (actual connection/transmission distance depends on the working environment) |
PIR sensing distance |
30meters(below 25°C at the Normal sensitivity) |
PIR sensing angle |
15~100 degrees according to the distance of the target |
Time from trigger to finish shooting |
Finish Triggering and Shooting within 0.4S |
Power supply |
Power supply with 12*AA battery |
Standby current |
50uA |
Interface |
SD card slot, USB DC power port |
Memory card |
16GB~256GB (Cass10) SD card supported |
Time stamp |
Includes series number (cam ID), longitude and latitude, temperature, moon phase, date, time and battery power level. |
Working temperature |
-40℃ - +70℃ |
Working humidity |
5% ~ 95% |
Ingress protection |
Tight dustproof and waterproof case structure, IP68 ingress protection. |
